Hautau Tornado 1 Pivot Hinges are state-of-the-art pivot hinges that sit flush with the sill bar. The Tornado 1 operates via 2 limited pivot points, allowing the window to be turned by 180°.
The sash release and brake adjusting screws are buried in the sash, allowing the hinges front & side surfaces to be completely smooth and free of any protruding screw heads.
The Tornado 1 Pivot Hinge Features
- Supplied in pairs
- With drilling cam
- Silver or white finish
- Compatible with round or straight timber windows
- Suitable for sash weights up to 175kg
- Rebate 11/4/11 (or 15/4/15 with corrective plates)
- Timber thickness 56mm or more
Full locking gear to go around the sash such as locking mechanisms and frame keeps also available by special request
