The Glas-O-Meter is a tool for measuring the thickness of glass window panes that are already installed as well as double glazed sealed units. The glass measuring tool can be used without needing to remove the glass panes first. The device is suitable for measuring glass thicknesses of up to approximately 120 mm.
The device also features an integrated optical thickness gauge which offers the possibility of determining the thickness of glass panes (from 2 – 25 mm). To take a measurement simply place the stop surface, with the base line on the pane, and read the glass thickness of the individual pane where the weaker reflection matches the scale.
Glass Measuring Tool Dimensions
– Length: 315 mm
– Width: 270 mm
– Weight: 0.376 kg
